Energy Counter
Value Description Menu path
Z L3-L1 Impedance, phase L3-L1 [Operation
/Measured Values
/Impedance
/Z L3-L1]
phi(Z L3-L1) Angle of the impedance Z L3-L1 [Operation
/Measured Values
/Impedance
/Z L3-L1]
R L3-L1 Resistance part of impedance Z L3-L1 [Operation
/Measured Values
/Impedance
/Z L3-L1]
X L3-L1 Reactance part of impedance Z L3-L1 [Operation
/Measured Values
/Impedance
/Z L3-L1]
Z1 Measured positive-sequence impedance [Operation
/Measured Values
/Impedance
/Z1]
phi(Z1) Angle of the impedance Measured positive-sequence
impedance
[Operation
/Measured Values
/Impedance
/Z1]
R1 Resistance part of impedance Measured positive-
sequence impedance
[Operation
/Measured Values
/Impedance
/Z1]
X1 Reactance part of impedance Measured positive-
sequence impedance
[Operation
/Measured Values
/Impedance
/Z1]
