Recorders
Parameter Description Setting range Default Menu path
Auto
overwriting
If there is no more free memory capacity
left, the oldest file will be overwritten.
inactive,
active
active [Device Para
/Recorders
/Disturb rec]
Pre-trigger time The pre trigger time is set in percent of the
»Max file size« value. It corresponds to the
part of recording before the onset of the
trigger event.
0 - 99% 20% [Device Para
/Recorders
/Disturb rec]
Post-trigger
time
The post trigger time is set in percent of the
»Max file size« value. It is the remaining
time of the »Max file size«, depending on
the »Pre-trigger time« setting and the
duration of the trigger event, but at
maximum the »Post-trigger time« set here.
0 - 99% 20% [Device Para
/Recorders
/Disturb rec]
Max file size The maximum storage capacity per record,
including pre-trigger and post-trigger time.
The amount of records depends on the size
of each record, on the max. file size (set
here), and on the total storage capacity.
0.1 - 15.0s 2s [Device Para
/Recorders
/Disturb rec]
Disturbance Recorder Input States
Name Description Assignment via
Start1-I State of the module input:: Trigger event / start
recording if:
[Device Para
/Recorders
/Disturb rec]
Start2-I State of the module input:: Trigger event / start
recording if:
[Device Para
/Recorders
/Disturb rec]
Start3-I State of the module input:: Trigger event / start
recording if:
[Device Para
/Recorders
/Disturb rec]
Start4-I State of the module input:: Trigger event / start
recording if:
[Device Para
/Recorders
/Disturb rec]
Start5-I State of the module input:: Trigger event / start
recording if:
[Device Para
/Recorders
/Disturb rec]
299 MCDGV4 DOK-HB-MCDGV4-2E
