Woodward HighPROTEC - Page 300

Recorders
Name Description Assignment via
Start6-I State of the module input:: Trigger event / start
recording if:
[Device Para
/Recorders
/Disturb rec]
Start7-I State of the module input:: Trigger event / start
recording if:
[Device Para
/Recorders
/Disturb rec]
Start8-I State of the module input:: Trigger event / start
recording if:
[Device Para
/Recorders
/Disturb rec]
Disturbance Recorder Signals
Signal Description
recording Signal: Recording
memory full Signal: Memory full
Clear fail Signal: Clear failure in memory
Res all records Signal: All records deleted
Res rec Signal: Delete record
Man Trigger Signal: Manual Trigger
Special Parameters of the Disturbance Recorder
Value Description Default Size Menu path
Rec state Recording state Ready Ready,
Recording,
Writing file,
Trigger Blo
[Operation
/Status Display
/Recorders
/Disturb rec]
Error code Error code OK OK,
Write err,
Clear fail,
Calculation
err,
File not
found,
Auto
overwriting
off
[Operation
/Status Display
/Recorders
/Disturb rec]
