Woodward HighPROTEC - Page 324

Communication Protocols
Parameter Description Setting range Default Menu path
Optical rest
position
Optical rest position Light off,
Light on
Light on [Device Para
/Modbus
/
Communication
/General
Settings]
Config Bin Inp1 Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
Latched Config
Bin Inp1
Latched Configurable Binary Input inactive,
active
inactive [Device Para
/Modbus
/Configb
Registers
/States]
Config Bin Inp2 Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
Latched Config
Bin Inp2
Latched Configurable Binary Input inactive,
active
inactive [Device Para
/Modbus
/Configb
Registers
/States]
Config Bin Inp3 Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
Latched Config
Bin Inp3
Latched Configurable Binary Input inactive,
active
inactive [Device Para
/Modbus
/Configb
Registers
/States]
Config Bin Inp4 Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
324 MCDGV4 DOK-HB-MCDGV4-2E
