Woodward HighPROTEC - Page 325

Communication Protocols
Parameter Description Setting range Default Menu path
Latched Config
Bin Inp4
Latched Configurable Binary Input inactive,
active
inactive [Device Para
/Modbus
/Configb
Registers
/States]
Config Bin Inp5 Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
Latched Config
Bin Inp5
Latched Configurable Binary Input inactive,
active
inactive [Device Para
/Modbus
/Configb
Registers
/States]
Config Bin Inp6 Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
Latched Config
Bin Inp6
Latched Configurable Binary Input inactive,
active
inactive [Device Para
/Modbus
/Configb
Registers
/States]
Config Bin Inp7 Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
Latched Config
Bin Inp7
Latched Configurable Binary Input inactive,
active
inactive [Device Para
/Modbus
/Configb
Registers
/States]
Config Bin Inp8 Virtual Digital Input. This corresponds to a
virtual binary output of the protective
device.
1..n,
Assignment List
-.- [Device Para
/Modbus
/Configb
Registers
/States]
325 MCDGV4 DOK-HB-MCDGV4-2E
