Switchgear/Breaker – Manager
Parameter Description Setting range Default Menu path
t-TripCmd Minimum hold time of the OFF-command
(circuit breaker, load break switch)
0 - 300.00s 0.2s [Control
/SG
/SG[1]
/Trip Manager]
Latched Defines whether the Binary Output Relay
will be Latched when it picks up.
inactive,
active
inactive [Control
/SG
/SG[1]
/Trip Manager]
Ack TripCmd Ack TripCmd 1..n,
Assignment List
-.- [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd1 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds Id.TripCmd [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd2 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds IdH.TripCmd [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd3 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds I[1].TripCmd [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd4 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds V[1].TripCmd [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd5 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds V[2].TripCmd [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd6 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds f[1].TripCmd [Control
/SG
/SG[1]
/Trip Manager]
