Switchgear/Breaker – Manager
Parameter Description Setting range Default Menu path
Off Cmd7 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds f[2].TripCmd [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd8 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds PQS[1].TripC
md
[Control
/SG
/SG[1]
/Trip Manager]
Off Cmd9 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds -.- [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd10 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds -.- [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd11 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds -.- [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd12 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds -.- [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd13 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds -.- [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd14 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds -.- [Control
/SG
/SG[1]
/Trip Manager]
Off Cmd15 Off Command to the Circuit Breaker if the
state of the assigned signal becomes true.
1..n, Trip Cmds -.- [Control
/SG
/SG[1]
/Trip Manager]
