Installation and Connection
OR-4X – Output Relays
The Output Relays are potential-free make contacts. In the Assignment / Output Relays section, the assignment of
the Output Relays is specified. The changeable signals are listed in the Assignment List section.
Ensure the correct tightening torques.
Please carefully consider the current carrying capacity of the Output Relays.
Please refer to the Technical Data.
61 MCDGV4 DOK-HB-MCDGV4-2E
0,56 - 0,79 Nm
5-7 lb·in
0,3 Nm
2.65 lb·in
