Protective Elements
Parameter Description Setting range Default Menu path
ExBlo Fc Activate (allow) or inactivate (disallow)
blocking of the module/stage. This
parameter is only effective if a signal is
assigned to the corresponding global
protection parameter. If the signal becomes
true, those modules/stages are blocked that
are parameterized "ExBlo Fc=active".
inactive,
active
inactive [Protection
Para
/<1..4>
/Diff-Prot
/IdG[1]]
Blo TripCmd Permanent blocking of the Trip Command of
the module/stage.
inactive,
active
inactive [Protection
Para
/<1..4>
/Diff-Prot
/IdG[1]]
ExBlo TripCmd
Fc
Activate (allow) or inactivate (disallow)
blocking of the module/stage. This
parameter is only effective if a signal is
assigned to the corresponding global
protection parameter. If the signal becomes
true, those modules/stages are blocked that
are parameterized "ExBlo TripCmd
Fc=active".
inactive,
active
inactive [Protection
Para
/<1..4>
/Diff-Prot
/IdG[1]]
IdG min Constant minimum pickup current (earth
differential current). Pickup value of the
differential current based on the rated
current Ib of the related protection object.
0.05 - 1.00Ib 0.05Ib [Protection
Para
/<1..4>
/Diff-Prot
/IdG[1]]
IdG(Is0) Starting point of the static tripping
characteristic at Is0
0.00 - 1.00Ib 0.1Ib [Protection
Para
/<1..4>
/Diff-Prot
/IdG[1]]
IdG(Is1) Breaking point of the static tripping
characteristic at Is1
0.2 - 2.00Ib 0.2Ib [Protection
Para
/<1..4>
/Diff-Prot
/IdG[1]]
IdG(Is2) Value of the static tripping characteristic at
Is2
1.0 - 8.0Ib 2.0Ib [Protection
Para
/<1..4>
/Diff-Prot
/IdG[1]]
671 MCDGV4 DOK-HB-MCDGV4-2E
