Protective Elements
Parameter Description Setting range Default Menu path
Is1 Breaking point of the static tripping
characteristic when Is1
0.5 - 5.0Ib 2.0Ib [Protection
Para
/<1..4>
/Diff-Prot
/IdG[1]]
Is2 Value of the static tripping characteristic at
Is2
5.0 - 10.0Ib 10.0Ib [Protection
Para
/<1..4>
/Diff-Prot
/IdG[1]]
Restricted Ground Fault Protection Module Input States
Name Description Assignment via
ExBlo1-I Module input state: External blocking1 [Protection Para
/Global Prot Para
/Diff-Prot
/IdG[1]]
ExBlo2-I Module input state: External blocking2 [Protection Para
/Global Prot Para
/Diff-Prot
/IdG[1]]
ExBlo TripCmd-I Module input state: External Blocking of the Trip
Command
[Protection Para
/Global Prot Para
/Diff-Prot
/IdG[1]]
Restricted Ground Fault Protection Module Signals (Output States)
Signal Description
active Signal: active
ExBlo Signal: External Blocking
Blo TripCmd Signal: Trip Command blocked
ExBlo TripCmd Signal: External Blocking of the Trip Command
Alarm Signal: Alarm
Trip Signal: Trip
TripCmd Signal: Trip Command
