Protective Elements
Parameter Description Setting range Default Menu path
ExBlo Fc Activate (allow) or inactivate (disallow)
blocking of the module/stage. This
parameter is only effective if a signal is
assigned to the corresponding global
protection parameter. If the signal becomes
true, those modules/stages are blocked that
are parameterized "ExBlo Fc=active".
inactive,
active
inactive [Protection
Para
/<1..4>
/V/f>-Prot
/V/f>[1]]
Blo TripCmd Permanent blocking of the Trip Command of
the module/stage.
inactive,
active
inactive [Protection
Para
/<1..4>
/V/f>-Prot
/V/f>[1]]
ExBlo TripCmd
Fc
Activate (allow) or inactivate (disallow)
blocking of the module/stage. This
parameter is only effective if a signal is
assigned to the corresponding global
protection parameter. If the signal becomes
true, those modules/stages are blocked that
are parameterized "ExBlo TripCmd
Fc=active".
inactive,
active
inactive [Protection
Para
/<1..4>
/V/f>-Prot
/V/f>[1]]
V/f> If the value is exceeded, the element will be
started.
80.0 - 400.0% 100.0% [Protection
Para
/<1..4>
/V/f>-Prot
/V/f>[1]]
Curve Shape Tripping characteristics of V/f Over-
Excitation protection.
DEFT,
Inv A,
Inv B,
Inv C
DEFT [Protection
Para
/<1..4>
/V/f>-Prot
/V/f>[1]]
t Tripping delay
Only available if: Characteristic = DEFT
0.00 - 600.00s 1.00s [Protection
Para
/<1..4>
/V/f>-Prot
/V/f>[1]]
t-multiplier Time Multiplier for inverse characteristics.
Only available if: Characteristic = INV
0.05 - 600.00 1.00 [Protection
Para
/<1..4>
/V/f>-Prot
/V/f>[1]]
