Protective Elements
Parameter Description Setting range Default Menu path
t-reset Reset time for inverse characteristics.
Only available if: Characteristic = INV
0.0 - 1000.0s 1.0s [Protection
Para
/<1..4>
/V/f>-Prot
/V/f>[1]]
Input States of the Volts/Hertz Element
Name Description Assignment via
ExBlo1-I Module input state: External blocking1 [Protection Para
/Global Prot Para
/V/f>-Prot
/V/f>[1]]
ExBlo2-I Module input state: External blocking2 [Protection Para
/Global Prot Para
/V/f>-Prot
/V/f>[1]]
ExBlo TripCmd-I Module input state: External Blocking of the Trip
Command
[Protection Para
/Global Prot Para
/V/f>-Prot
/V/f>[1]]
Signals of the Volts/Hertz (Output States)
Signal Description
active Signal: active
ExBlo Signal: External Blocking
Blo TripCmd Signal: Trip Command blocked
ExBlo TripCmd Signal: External Blocking of the Trip Command
Alarm Signal: Alarm Overexcitation
Trip Signal: Trip
TripCmd Signal: Trip Command
791 MCDGV4 DOK-HB-MCDGV4-2E
