Protective Elements
Device Planning Parameters of the Out-of-Step Tripping Module
Parameter Description Options Default Menu path
Mode Mode do not use,
use
do not use [Device planning]
Global Protection Parameters of the Out-of-Step Tripping n Module
Parameter Description Setting range Default Menu path
ExBlo1 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/OST]
ExBlo2 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/OST]
ExBlo TripCmd External blocking of the Trip Command of
the module/the stage, if blocking is
activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/OST]
Setting Group Parameters of the Out-of-Step Tripping Module
The actually available value range for all impedance settings is dependent on
the Field Parameter setting »CT sec« . This dependency is not properly
reflected in the parameter table below.
• For »CT sec« = 1 A the min. value from the “Setting Range” table row
has to be multiplied by 5.
• For »CT sec« = 5 A the max. value from the “Setting Range” table row
has to be divided by 5.
Parameter Description Setting range Default Menu path
Function Permanent activation or deactivation of
module/stage.
inactive,
active
inactive [Protection
Para
/<1..4>
/OST
/General
Settings]
