Protective Elements
Parameter Description Setting range Default Menu path
ExBlo Fc Activate (allow) or inactivate (disallow)
blocking of the module/stage. This
parameter is only effective if a signal is
assigned to the corresponding global
protection parameter. If the signal becomes
true, those modules/stages are blocked that
are parameterized "ExBlo Fc=active".
inactive,
active
inactive [Protection
Para
/<1..4>
/OST
/General
Settings]
Blo TripCmd Permanent blocking of the Trip Command of
the module/stage.
inactive,
active
inactive [Protection
Para
/<1..4>
/OST
/General
Settings]
ExBlo TripCmd
Fc
Activate (allow) or inactivate (disallow)
blocking of the module/stage. This
parameter is only effective if a signal is
assigned to the corresponding global
protection parameter. If the signal becomes
true, those modules/stages are blocked that
are parameterized "ExBlo TripCmd
Fc=active".
inactive,
active
inactive [Protection
Para
/<1..4>
/OST
/General
Settings]
Meas Circuit
Superv
Activates the use of the measuring circuit
supervision. In this case the module will be
blocked if a measuring circuit supervision
module (e.g. LOP, VTS) signals a disturbed
measuring circuit (e.g. caused by a fuse
failure).
inactive,
active
inactive [Protection
Para
/<1..4>
/OST
/General
Settings]
I1 min Minimum value positive phase sequence
current
0.02 - 4.00In 0.20In [Protection
Para
/<1..4>
/OST
/General
Settings]
I2 max Maximum value negative sequence current 0.02 - 1.00In 0.20In [Protection
Para
/<1..4>
/OST
/General
Settings]
