Protective Elements
Signals (Output States) of the Phase Distance Protection Module
Signal Description
active Signal: active
ExBlo Signal: External Blocking
Blo TripCmd Signal: Trip Command blocked
ExBlo TripCmd Signal: External Blocking of the Trip Command
Blo by Power Swing Signal: Distance Protection blocked by Power Swing detection
Blo by LB Signal: Distance Protection blocked by Load Blinder module
Blo by MeasCircSupv Blocked by Measuring Circuit Supervision
Started Signal: Distance Protection has been started.
Alarm Alarm
Trip Trip
TripCmd Signal: Trip Command
Fault type L1-L2 Fault type: L1-L2
Fault type L2-L3 Fault type: L2-L3
Fault type L3-L1 Fault type: L3-L1
Fault type L1-L2-L3 Fault type: L1-L2-L3
Active AdaptSet Active Adaptive Parameter
DefaultSet Signal: Default Parameter Set
AdaptSet 1 Signal: Adaptive Parameter 1
AdaptSet 2 Signal: Adaptive Parameter 2
843 MCDGV4 DOK-HB-MCDGV4-2E
