Protective Elements
Parameter Description Setting range Default Menu path
Trip delay time This specifies the delay from pickup to CB
tripping. (Note that since the phase distance
protection is mainly used as a backup this
time delay should be coordinated carefully
with the primary tripping time and the
latency of CB failure protection.)
0.00 - 300.00s 0.50s [Protection
Para
/<1..4>
/Z
/Z[1]
/General
Settings]
Input States of the Phase Distance Protection Module
Name Description Assignment via
ExBlo1-I Module input state: External blocking1 [Protection Para
/Global Prot Para
/Z
/Z[1]]
ExBlo2-I Module input state: External blocking2 [Protection Para
/Global Prot Para
/Z
/Z[1]]
ExBlo TripCmd-I Module input state: External Blocking of the Trip
Command
[Protection Para
/Global Prot Para
/Z
/Z[1]]
Blo by Power
Swing-I
Module input state: Blocking (of the distance
protection) by Power Swing detection
[Protection Para
/Global Prot Para
/Z
/Z[1]]
Blo by LB-I Module input state: Blocking (of the distance
protection) by Load Blinder module
[Protection Para
/Global Prot Para
/Z
/Z[1]]
AdaptSet1-I Module input state: Adaptive Parameter1 [Protection Para
/Global Prot Para
/Z
/Z[1]]
AdaptSet2-I Module input state: Adaptive Parameter2 [Protection Para
/Global Prot Para
/Z
/Z[1]]
