Protective Elements
Parameter Description Setting range Default Menu path
Polyg.Neg.Imp.
Angle
Polygon characteristic: The »Negative
Impedance Angle« defines the impedance
angle in the reverse (backward) direction
(third quadrant).
225 - 270° 240° [Protection
Para
/<1..4>
/Z
/Z[1]
/Characteristic]
Polyg.Neg.Imp.
R.Ang.1
Polygon characteristic: The »Negative
Impedance Reach Angle 1« is the tilt angle
of the line element which is starting at the
negative impedance reach tip and and
spreads to the right, i.e. into the fourth
quadrant.
-30 - 30° 0° [Protection
Para
/<1..4>
/Z
/Z[1]
/Characteristic]
Polyg.Neg.Imp.
R.Ang.2
Polygon characteristic: The »Negative
Impedance Reach Angle 2« is the tilt angle
of the line element which is starting at the
negative impedance reach tip and spreads
on the left side in the third quadrant.
150 - 180° 180° [Protection
Para
/<1..4>
/Z
/Z[1]
/Characteristic]
Polyg.Neg.Resis
.Reach
Polygon characteristic: The »Negative
Resistive Reach« determines the reach on
the negative R-axis (secondary value).
0.2 - 500.0Ω 1.6Ω [Protection
Para
/<1..4>
/Z
/Z[1]
/Characteristic]
Polyg.Neg.Resis
.Ang.1
Polygon characteristic: The »Negative
Resistive Angle 1« is a tilt angle in the
second quadrant. The area left from the
blinder is excluded from the operating area.
60 - 120° 105° [Protection
Para
/<1..4>
/Z
/Z[1]
/Characteristic]
Polyg.Neg.Resis
.Ang.2
Polygon characteristic: The »Negative
Resistive Angle 2« is a tilt angle in the third
quadrant. The area left from the blinder is
excluded from the operating area.
225 - 270° 270° [Protection
Para
/<1..4>
/Z
/Z[1]
/Characteristic]
