Protective Elements
Parameter Description Setting range Default Menu path
Meas Circuit
Superv
Activates the use of the measuring circuit
supervision. In this case the module will be
blocked if a measuring circuit supervision
module (e.g. LOP, VTS) signals a disturbed
measuring circuit (e.g. caused by a fuse
failure).
inactive,
active
inactive [Protection
Para
/<1..4>
/LB]
I1 min Minimum value positive phase sequence
current
0.10 - 4.00In 0.50In [Protection
Para
/<1..4>
/LB]
I2 max Maximum value negative sequence current 0.02 - 1.00In 0.20In [Protection
Para
/<1..4>
/LB]
Imp. Circ. Rd The resistance where the Load Blinder area
starts (secondary value), i. e. the radius of
the impedance circle defining the Load
Blinder area (together with the two blinder
angles).
0.1 - 500.0Ω 50.0Ω [Protection
Para
/<1..4>
/LB]
Imp. Angle 1 Blinder angle No. 1. This angle is measured
counter-clockwise from the R-axis.
0 - 45° 30° [Protection
Para
/<1..4>
/LB]
Imp. Angle 2 Blinder angle No. 2. This angle is measured
clockwise from the R-axis.
-45 - 0° -30° [Protection
Para
/<1..4>
/LB]
t-Delay Delay time between the signals »Pickup«
and »Operate«.
0.00 - 300.00s 0.00s [Protection
Para
/<1..4>
/LB]
Input States of the Load Blinder Module
Name Description Assignment via
ExBlo1-I Module input state: External blocking1 [Protection Para
/Global Prot Para
/LB]
ExBlo2-I Module input state: External blocking2 [Protection Para
/Global Prot Para
/LB]
