Protective Elements
Signals (Output States) of the Load Blinder Module
Signal Description
active Signal: active
ExBlo Signal: External Blocking
Blo by MeasCircSupv Blocked by Measuring Circuit Supervision
Pickup Signal that the measured system impedance is within the Load Blinder
area.
Operate Signal that the measured system impedance is within the Load Blinder area
for at least the duration t-Delay.
