Protective Elements
Device planning parameters of the asymmetry module
Parameter Description Options Default Menu path
Mode Unbalance Protection: Supervision of
the Voltage System
do not use,
V1>,
V1<,
V2>
do not use [Device planning]
Global protection parameter of the asymmetry-module
Parameter Description Setting range Default Menu path
ExBlo1 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.1
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/V-Prot
/V012[1]]
ExBlo2 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.2
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/V-Prot
/V012[1]]
ExBlo TripCmd External blocking of the Trip Command of
the module/the stage, if blocking is
activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/V-Prot
/V012[1]]
929 MCDGV4 DOK-HB-MCDGV4-2E
