Woodward HighPROTEC - Page 930

Protective Elements
Parameter set parameters of the asymmetry module
Parameter Description Setting range Default Menu path
Function Permanent activation or deactivation of
module/stage.
inactive,
active
inactive [Protection
Para
/<1..4>
/V-Prot
/V012[1]]
ExBlo Fc Activate (allow) or inactivate (disallow)
blocking of the module/stage. This
parameter is only effective if a signal is
assigned to the corresponding global
protection parameter. If the signal becomes
true, those modules/stages are blocked that
are parameterized "ExBlo Fc=active".
inactive,
active
inactive [Protection
Para
/<1..4>
/V-Prot
/V012[1]]
Blo TripCmd Permanent blocking of the Trip Command of
the module/stage.
inactive,
active
inactive [Protection
Para
/<1..4>
/V-Prot
/V012[1]]
ExBlo TripCmd
Fc
Activate (allow) or inactivate (disallow)
blocking of the module/stage. This
parameter is only effective if a signal is
assigned to the corresponding global
protection parameter. If the signal becomes
true, those modules/stages are blocked that
are parameterized "ExBlo TripCmd
Fc=active".
inactive,
active
inactive [Protection
Para
/<1..4>
/V-Prot
/V012[1]]
V1> Positive Phase Sequence Overvoltage
Only available if: Device planning:
V012.Mode = V1>
0.01 - 2.00Vn 1.00Vn [Protection
Para
/<1..4>
/V-Prot
/V012[1]]
V1< Positive Phase Sequence Undervoltage
Only available if: Device planning:
V012.Mode = V1<
0.01 - 2.00Vn 1.00Vn [Protection
Para
/<1..4>
/V-Prot
/V012[1]]
V2> Negative Phase Sequence Overvoltage
Only available if: Device planning:
V012.Mode = V2>
0.01 - 2.00Vn 1.00Vn [Protection
Para
/<1..4>
/V-Prot
/V012[1]]
930 MCDGV4 DOK-HB-MCDGV4-2E
