Protective Elements
Parameter Description Setting range Default Menu path
MinLiveBusVolt
age
Minimum Live Bus voltage (Live bus
detected, when all three phase bus voltages
are above this limit).
0.10 - 2.00Vn 0.65Vn [Protection
Para
/<1..4>
/Intercon-Prot
/Sync
/
DeadLiveVLeve
ls]
MaxDeadBusVo
ltage
Maximum Dead Bus voltage (Dead bus
detected, when all three phase bus voltages
are below this limit).
0.01 - 1.00Vn 0.03Vn [Protection
Para
/<1..4>
/Intercon-Prot
/Sync
/
DeadLiveVLeve
ls]
MinLiveLineVolt
age
Minimum Live Line voltage (Live line
detected, when line voltage above this
limit).
0.10 - 2.00Vn 0.65Vn [Protection
Para
/<1..4>
/Intercon-Prot
/Sync
/
DeadLiveVLeve
ls]
MaxDeadLineVo
ltage
Maximum Dead Line voltage (Dead Line
detected, when line voltage below this
limit).
0.01 - 1.00Vn 0.03Vn [Protection
Para
/<1..4>
/Intercon-Prot
/Sync
/
DeadLiveVLeve
ls]
t-VoltDead Voltage dead time (A Dead Bus/Line
condition will be accepted only if the voltage
falls below the set dead voltage levels
longer than this time setting).
0.000 -
300.000s
0.167s [Protection
Para
/<1..4>
/Intercon-Prot
/Sync
/
DeadLiveVLeve
ls]
