Protective Elements
Setting Group Parameters of the Synchrocheck Fault Module
Parameter Description Setting range Default Menu path
Function Permanent activation or deactivation of
module/stage.
inactive,
active
inactive [Protection
Para
/<1..4>
/Intercon-Prot
/Sync
/General
Settings]
ExBlo Fc Activate (allow) or inactivate (disallow)
blocking of the module/stage. This
parameter is only effective if a signal is
assigned to the corresponding global
protection parameter. If the signal becomes
true, those modules/stages are blocked that
are parameterized "ExBlo Fc=active".
inactive,
active
inactive [Protection
Para
/<1..4>
/Intercon-Prot
/Sync
/General
Settings]
Bypass Fc Allowing to bypass the Synchrocheck, if the
state signal that is assigned to the
parameter with the same name within the
Global Parameters (logic input) becomes
true.
inactive,
active
inactive [Protection
Para
/<1..4>
/Intercon-Prot
/Sync
/General
Settings]
SyncMode Synchrocheck mode: GENERATOR2SYSTEM
= Synchronizing generator to system
(breaker close initiate needed).
SYSTEM2SYSTEM = SynchronCheck between
two systems (Stand-Alone, no breaker info
needed)
System2System
,
Generator2Syst
em
System2Syste
m
[Protection
Para
/<1..4>
/Intercon-Prot
/Sync
/Mode / Times]
t-
MaxCBCloseDel
ay
Maximum circuit breaker close time delay
(Only used for GENERATOR-SYSTEM working
mode and is critical for a correct
synchronized switching)
Only available if: SyncMode =
System2System
0.00 - 300.00s 0.05s [Protection
Para
/<1..4>
/Intercon-Prot
/Sync
/Mode / Times]
t-
MaxSyncSuperv
Synchron-Run timer: Max. time allowed for
synchronizing process after a close initiate.
Only used for GENERATOR2SYSTEM working
mode.
Only available if: SyncMode =
System2System
0.00 - 3000.00s 30.00s [Protection
Para
/<1..4>
/Intercon-Prot
/Sync
/Mode / Times]
