Protective Elements
Device Planning Parameters of the Synchrocheck Module
Parameter Description Options Default Menu path
Mode Mode do not use,
use
do not use [Device planning]
Global Protection Parameters of the Synchrocheck Module
Parameter Description Setting range Default Menu path
ExBlo1 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/Intercon-Prot
/Sync]
ExBlo2 External blocking of the module, if blocking
is activated (allowed) within a parameter set
and if the state of the assigned signal is
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/Intercon-Prot
/Sync]
Bypass The Synchrocheck will be bypassed if the
state of the assigned signal (logic input)
becomes true.
1..n, DI-
LogicList
-.- [Protection
Para
/Global Prot
Para
/Intercon-Prot
/Sync]
CB Pos Detect Criterion by which the Circuit Breaker Switch
Position is to be detected.
-.-,
SG[1].Pos,
SG[2].Pos,
SG[3].Pos,
SG[4].Pos,
SG[5].Pos,
SG[6].Pos
SG[1].Pos [Protection
Para
/Global Prot
Para
/Intercon-Prot
/Sync]
CBCloseInitiate Breaker Close Initiate with synchronism
check from any control sources (e.g. HMI /
SCADA). If the state of the assigned signal
becomes true, a Breaker Close will be
initiated (Trigger Source).
1..n,
SyncRequestLis
t
-.- [Protection
Para
/Global Prot
Para
/Intercon-Prot
/Sync]
943 MCDGV4 DOK-HB-MCDGV4-2E
