Protective Elements
Parameter Description Setting range Default Menu path
Phi-Power Trigger Phi-Power (Positive Phase Sequence
System)
Only available if: QV-Method = Power Angle
Supervision
0 - 10° 3° [Protection
Para
/<1..4>
/Intercon-Prot
/Q->&V<
/Decoupling]
Q min QV Trigger for the Reactive Power (Positive
Phase Sequence System)
Only available if: QV-Method = Pure
Reactive Power Superv
0.01 - 0.20Sn 0.05Sn [Protection
Para
/<1..4>
/Intercon-Prot
/Q->&V<
/Decoupling]
t1-QV First timer. If this timer has elapsed, a trip
signal will be issued to the (local) energy
resource.
0.00 - 2.00s 0.5s [Protection
Para
/<1..4>
/Intercon-Prot
/Q->&V<
/Decoupling]
t2-QV Second timer. If this timer is elapsed, the an
trip signal will be issued to the PCC (Point of
Common Coupling)
0.00 - 4.00s 1.5s [Protection
Para
/<1..4>
/Intercon-Prot
/Q->&V<
/Decoupling]
Input States of the Q->&V< Module
Name Description Assignment via
ExBlo1-I Module input state: External blocking1 [Protection Para
/Global Prot Para
/Intercon-Prot
/Q->&V<]
ExBlo2-I Module input state: External blocking2 [Protection Para
/Global Prot Para
/Intercon-Prot
/Q->&V<]
Q->&V< Module Signals (Output States)
Signal Description
active Signal: active
