Xerox 459
0/41
10 Copier
/Print
er User Guide
4-75
4. Mailbox M
anagemen
t
Change the Document Name
Y
ou can rename do
cuments.
NOTE:
When selecting
multip
le document
s, you c
annot rename
documents
.
1.
Select
Change
Document Name
.
2.
Enter document name using the key
board shown.
3.
Select
Save
and th
en
Close
to keep the changed name.
