Xerox 4590/4110 Copier/Printer User Guide
11-56
11. Problem Solving
Paper Jams in Tray 8 (Post-Process inserter)
Following describes how to remedy paper jams that occur in the
Post-Process Inserter.
1. Press the Cover button.
2. Open the cover 1e and then remove the jammed paper and all
paper loaded in the Post-Process Inserter.
KEY POINT: When two or more sheets of paper are loaded,
remove all of the sheets from the tray.
NOTE: If paper is torn, check for any torn pieces of paper inside
the machine.
3. Fan the paper you removed, making sure that all four corners
are neatly aligned, and then load them again.
4. Push the cover 1e until you hear it click into place.
NOTE: A message will be displayed and the machine will not
operate if the cover is even slightly open.
To Next Page
