Xerox 4590/4110 Copier/Printer User Guide
11-71
11. Problem Solving
3. Return lever 2b to the original position.
4. Close the Finisher right cover.
NOTE: A message will be displayed and the machine will not
operate if the Finisher right cover is even slightly open.
Paper jams at knob 2c, levers 2e/2f and tri-fold output tray 2d.
1. Make sure that the machine has stopped and then open the
right cover on the light finisher.
2. Pull out the tri-fold output tray 2d, swing lever 2e to the right,
and remove the jammed paper.
NOTE: If paper is torn, check for any torn pieces of paper inside
the machine.
