Xerox 459
0/41
10 Copier/
Printer
User Guide
2-50
2. C
opy
Output F
ormat tab
On the
Output Forma
t
screen, you can configure fe
atures for
scanning do
cuments.
1.
On the
All Servic
es
screen
, sele
ct
Copy
.
2.
Select t
he
Output Format
tab and then select
a feature on
the
Output Format
screen t
hat appears.
77
79
