Xerox 4590/4110 Copier/Printer User Guide
7-8
7. Paper and Other Media
3. Push the tray in gently until it comes to a stop.
Load paper in the optional Oversized High Capacity Feeder (Tray 6)
NOTE: This optional tray is not available with the 4590 Copier/
Printer.
1. Pull out the tray towards you until it stops.
WARNING: When pulling out the paper tray, do it slowly. If pulled
out with too much force, the tray can hit and injure your knees.
2. Squeeze the handle on the paper guide (A) and slide the
guide to the desired paper size. Squeeze the handle on the
paper guide (B) and slide the guide to the desired paper
size.
3. Fan the sheets before loading them into the tray. With the
side to be printed on facing up, load and align the paper
stack in the lower right corner of the tray as shown below.
NOTE: Do not load paper exceeding the maximum fill line. Doing
so might cause paper jams or machine malfunctions. When
loading drilled stock, place the paper with its drilled side to the
right. When loading tab stock, place the tabs to the left.
4. Slide both paper guides to just touch the edges of the paper
stack.
NOTE: Position the paper guides correctly to match the paper
size. If the position of the paper guide is not correct, the paper
may not be fed properly and paper jams may occur.
