Xerox 4590/4110 Copier/Printer User Guide
11-80
11. Problem Solving
Paper jams at lever 1d
1. Open the front cover of the high capacity feeder unit.
2. Move lever 1d upwards and remove the jammed paper.
NOTE: If paper is torn, check for any torn pieces of paper inside
the machine.
3. Return lever 1d to the original position.
4. Close the front cover of the high capacity feeder unit.
NOTE: A message will be displayed and the machine will not
operate if the High Capacity Feeder Unit front cover is
even slightly open.
