Xerox 4590/4110 Copier/Printer User Guide
7-16
7. Paper and Other Media
1. Pull out the tray towards you until it stops.
WARNING: When pulling out the paper tray, do it slowly. If pulled
out with too much force, the tray can hit and injure your knees.
2. Remove any paper loaded on the tray.
3. Loose the screw on the right to remove your side and the
other side guide.
4. Attach the guides according to the hole of the paper size to
change, and tighten the screws.
To Next Page
