Xerox 4110 User Manual

Xerox 4590/4110 Copier/Printer User Guide
11-59
11. Problem Solving
4. If the jam occurs at the top of the transfer module or inside the
fuser unit, remove the jammed paper by pulling it out towards
the left.
If the jammed paper cannot be removed, lift up the lever 2c
and then remove the jammed paper.
KEY POINT: Never touch the six protrusions which are visible
when you lift up the lever 2c.
5. Lift up the lever 2c as necessary, shift the lever 2d, and then
remove the jammed paper.
6. Turn the knob 2f as necessary and then remove the jammed
paper.
WARNING: Never touch a labeled area
(found on the fuser unit or
nearby) indicating “High
Temperature” and “Caution.”
Contact can lead to burns.

Xerox 4110 Specifications

General

Brand	Xerox
Model	4110
Category	Printer
Language	English
