Xerox 4590/4110 Copier/Printer User Guide
11-74
11. Problem Solving
2. Pull out unit 4.
3. Turn knob 4a to the left to remove all the jammed paper from
the left side of the unit 4.
NOTE: If paper is torn, check for any torn pieces of paper inside
the machine.
4. If the paper cannot be removed, pull up on the green lever on
the right top cover unit 4 and remove all the jammed paper.
5. Return unit 4 to the original position.
6. Close the finisher right cover.
NOTE: A message will be displayed and the machine will not
operate if the Finisher right cover is even slightly open.
