Xerox 4590/4110 Copier/Printer User Guide
2-44
2. Copy
No Shift
Copies are made without the position of the document image
being shifted.
Auto Center
Copies are made so that the center of the document matches the
center of the paper.
Image Shift/Variable Shift
You can set the margin amount within the range from 1.9 to 0 to
1.9 inches (50 to 0 to 50 mm) in 0.1 inch or 1 mm increments.
Side 1
Displays the Image Shift - Side 1 screen.
Side 2
Displays the Image Shift - Side 2 screen.
Mirror Shift
When copying with the same setting as Side 1, Check Mirror Shift.
Original Orientation
Refer to “Original Orientation” on page 2-49.
Image Shift - Side 1/Image Shift - Side 2 Screen
You can set the copy position/image shift of Side 1 or Side 2.
1. On the All Services screen, select Copy, then the Scan
Options tab. From the Scan Options screen that appears,
select Image Shift and then Side 1 or Side 2.
2. Select an item.
To Next Page
