3. Grasp the Staple Cartridge handle located at R1, and pull out the staple cartridge
from the finisher.
4. Check the inside of the finisher for any remaining staples, and if necessary, remove
them.
5. Open the staple cartridge unit as shown and remove the jammed staple.
Warning
To avoid injury to your fingers, carefully remove the jammed staples from the
cartridge.
6. Reinstall the cartridge unit to its original position in the finisher.
Xerox
®
Color 550/560/570 Printer13-34
User Guide
Standard/Booklet Maker Finisher
