Xerox WorkCentre 4265 Service Manual

January 2016
4-98
WorkCentre WorkCentre 4150/4250/4260WorkCentre 4150/4250/42604150/
REP 5.32
Repairs and Adjustments
6. Remove the Outer Cover from the Front Cover of the DADF (Figure 4).
NOTE: The Outer Cover is press-fit onto to Front Cover, and requires only a slot-head
screwdriver to remove.
Figure 4 Removing the Outer Cover from the Front Cover
7. Open the DADF and remove the two Front Cover mounting screws (Figure 5).
Figure 5 Removing the Front Cover Mounting Screws
1
Work a small slot-head screwdriver around
the perimeter of the Outer Cover, and sepa-
rate it from the Front Cover.
Outer Cover
Front Cover
1
Remove the two Front Cover
mounting screws.

Xerox WorkCentre 4265 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax, Email
Print Resolution (Max)	Up to 1200 x 1200 dpi
Memory (Standard)	2 GB
Memory (Maximum)	2 GB
Connectivity	10/100/1000Base-T Ethernet, USB 2.0
Paper Output	250 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Media Sizes Supported	Legal, Letter
Mobile Printing	Apple AirPrint
Duplex Printing	Automatic
Display	7-inch color touchscreen
