Chapter 2: MicroBlaze Architecture
Trace Control Register
The Trace Control Register (TCTRLR) is used to define the trace behavior. This register is a
write-only register. Issuing a read request has no effect, and undefined data is read. See the
following figure and table.
Trace Command Register
The Trace Command Register (TCMDR) is used to issue commands to clear, start, or stop
trace, as well as sample the number of trace items. This register is a write-only register.
Issuing a read request has no effect, and undefined data is read. See the following figure
and table.
X-Ref Target - Figure 2-31
Figure 2-31: Trace Control Register
04
Reserved
31 321
SR
SLSPCFH
22 521 6
Tracepoint
Level
X19767-082517
Table 2-50: Trace Control Register (TCTRLR)
Bits Name Description Reset Value
21:6 Tracepoint
Change corresponding breakpoint or watchpoint to a tracepoint
0
5:4 Level
Trace compression level:
00 = Complete trace, not available with C_DEBUG_EXTERNAL_TRACE
01 = Program flow
10 = Event
11 = Program flow and cycle count
00
3Full Halt
Debug Halt on full trace buffer or cycle count overflow
0
2Save PC
Level 01 and 11: Save new program counter for all taken branches
Level 10: Save new program counter for all function calls
0
1Save Load
Save load and get instruction new data value
0
0Save Return
Save new program counter for return instructions
0
X-Ref Target - Figure 2-32
Figure 2-32: Trace Command Register
04
Reserved
31 321
SAM
STOP
STACLR
X19768-091117
