Chapter 3: MicroBlaze Signal Interface Description
M_AXI_IC_AWLOCK
M_AXI_IC O
Master Lock type
M_AXI_IC_AWCACHE
M_AXI_IC O
Master Cache type
M_AXI_IC_AWPROT
M_AXI_IC O
Master Protection type
M_AXI_IC_AWQOS
M_AXI_IC O
Master Quality of Service
M_AXI_IC_AWVALID
M_AXI_IC O
Master Write address valid
M_AXI_IC_AWREADY
M_AXI_IC I
Slave Write address ready
M_AXI_IC_AWUSER
M_AXI_IC O
Master Write address user signals
M_AXI_IC_AWDOMAIN
M_ACE_IC O
Master Write address domain
M_AXI_IC_AWSNOOP
M_ACE_IC O
Master Write address snoop
M_AXI_IC_AWBAR
M_ACE_IC O
Master Write address barrier
M_AXI_IC_WDATA
M_AXI_IC O
Master Write data
M_AXI_IC_WSTRB
M_AXI_IC O
Master Write strobes
M_AXI_IC_WLAST
M_AXI_IC O
Master Write last
M_AXI_IC_WVALID
M_AXI_IC O
Master Write valid
M_AXI_IC_WREADY
M_AXI_IC I
Slave Write ready
M_AXI_IC_WUSER
M_AXI_IC O
Master Write user signals
M_AXI_IC_BID
M_AXI_IC I
Slave Response ID
M_AXI_IC_BRESP
M_AXI_IC I
Slave Write response
M_AXI_IC_BVALID
M_AXI_IC I
Slave Write response valid
M_AXI_IC_BREADY
M_AXI_IC O
Master Response ready
M_AXI_IC_BUSER
M_AXI_IC I
Slave Write response user signals
M_AXI_IC_WACK
M_ACE_IC O
Slave Write acknowledge
M_AXI_IC_ARID
M_AXI_IC O
Master Read address ID
M_AXI_IC_ARADDR
M_AXI_IC O
Master Read address
M_AXI_IC_ARLEN
M_AXI_IC O
Master Burst length
M_AXI_IC_ARSIZE
M_AXI_IC O
Master Burst size
M_AXI_IC_ARBURST
M_AXI_IC O
Master Burst type
M_AXI_IC_ARLOCK
M_AXI_IC O
Master Lock type
M_AXI_IC_ARCACHE
M_AXI_IC O
Master Cache type
M_AXI_IC_ARPROT
M_AXI_IC O
Master Protection type
M_AXI_IC_ARQOS
M_AXI_IC O
Master Quality of Service
M_AXI_IC_ARVALID
M_AXI_IC O
Master Read address valid
M_AXI_IC_ARREADY
M_AXI_IC I
Slave Read address ready
M_AXI_IC_ARUSER
M_AXI_IC O
Master Read address user signals
M_AXI_IC_ARDOMAIN
M_ACE_IC O
Master Read address domain
Table 3-1: Summary of MicroBlaze Core I/O (Cont’d)
Signal Interface I/O Description
