MicroBlaze Processor Reference Guide 210
UG984 (v2018.2) June 21, 2018 www.xilinx.com
Chapter 5: MicroBlaze Instruction Set Architecture
blei
Branch Immediate if Less or Equal
blei
rA, IMM
Branch Immediate if Less or Equal
bleid
rA, IMM
Branch Immediate if Less or Equal with Delay
1 0 1 1 1 1 D 0 0 1 1 rA IMM
0 6 11 16
31
Description
Branch if rA is less or equal to 0, to the instruction located in the offset value of IMM. The target of the
branch will be the instruction at address PC + IMM.
The mnemonic bleid will set the D bit. The D bit determines whether there is a branch delay slot or
not. If the D bit is set, it means that there is a delay slot and the instruction following the branch (that
is, in the branch delay slot) is allowed to complete execution before executing the target instruction.
If the D bit is not set, it means that there is no delay slot, so the instruction to be executed after the
branch is the target instruction.
Pseudocode
If rA <= 0 then
PC ← PC + sext(IMM)
else
PC
← PC + 4
if D = 1 then
allow following instruction to complete execution
Registers Altered
•PC
Latency
• 1 cycle (if branch is not taken, or successful branch prediction occurs)
• 2 cycles (if branch is taken and the D bit is set)
• 3 cycles (if branch is taken and the D bit is not set, or a branch prediction mispredict
occurs with
C_AREA_OPTIMIZED=0)
• 7-9 cycles (if a branch prediction mispredict occurs with
C_AREA_OPTIMIZED=2)
Notes
By default, Type B Instructions will take the 16-bit IMM field value and sign extend it to 32 bits to use
as the immediate operand. This behavior can be overridden by preceding the Type B instruction with
an imm instruction. See the instruction
“imm” for details on using 32-bit immediate values.
A delay slot must not be used by the following: imm, branch, or break instructions. Interrupts and
external hardware breaks are deferred until after the delay slot branch has been completed.
