MicroBlaze Processor Reference Guide 294
UG984 (v2018.2) June 21, 2018 www.xilinx.com
Chapter 5: MicroBlaze Instruction Set Architecture
swaph
Swap Halfwords
swaph
rD, rA
1 0 0 1 0 0 rD rA 0 0 0 0 0 0 0 1 1 1 1 0 0 0 1 0
0 6 11 16
31
Description
Swaps the contents of register rA treated as two halfwords, and places the result in rD. This effectively
converts the two halfwords in the register between endianness formats, either from little-endian to
big-endian or vice versa.
Pseudocode
(rD)[0:15] ← (rA)[16:31]
(rD)[16:31]
← (rA)[0:15]
Registers Altered
•rD
Latency
• 1 cycle
Note
This instruction is only valid if MicroBlaze is configured to use reorder instructions
(C_USE_REORDER_INSTR = 1).
Send Feedback

Xilinx MicroBlaze Specifications

General

Architecture	32-bit RISC
Cache	Configurable Instruction and Data Cache
Category	Soft Processor Core
Data Width	32-bit
Memory Management Unit (MMU)	Optional
Floating Point Unit (FPU)	Optional
Interrupt Controller	Configurable
Memory Management	Optional MMU
Configurability	Highly Configurable
Pipeline Stages	3-stage
FPGA Integration	Xilinx FPGAs
Bus Interface	PLB
Debug Interface	JTAG
Typical Clock Speed	Varies depending on FPGA and configuration (e.g., 100-400+ MHz)
Implementation	Soft core (synthesized logic)
Maximum Performance	Varies with FPGA and configuration
Debug Support	Integrated Debug Module
