MicroBlaze Processor Reference Guide 39
UG984 (v2018.2) June 21, 2018 www.xilinx.com
Chapter 2: MicroBlaze Architecture
Translation Look-Aside Buffer High Register (TLBHI)
The Translation Look-Aside Buffer High Register is used to access MMU Unified Translation
Look-Aside Buffer (UTLB) entries. It is controlled by the
C_USE_MMU configuration option on
MicroBlaze. The register is only implemented if
C_USE_MMU is greater than 1 (User Mode),
and
C_AREA_OPTIMIZED is set to 0 (Performance) or 2 (Frequency). When accessed with the
MFS and MTS instructions, the TLBHI is specified by setting Sa = 0x1004. When reading or
writing TLBHI, the UTLB entry indexed by the TLBX register is accessed.
The register is readable according to the memory management special registers parameter
C_MMU_TLB_ACCESS.
PID is also used when accessing a TLB entry:
• When writing TLBHI the value of PID is stored in the TID field of the TLB entry
• When reading TLBHI and MSR[UM] is not set, the value in the TID field is stored in PID
The UTLB is reset on bit stream download (reset value is 0x00000000 for all TLBHI entries).
28
n-4
W Write Through
When the parameter C_DCACHE_USE_WRITEBACK is set to 1, this
bit controls caching policy. A write-through policy is selected when
set to 1, and a write-back policy is selected otherwise.
This bit is fixed to 1, and write-through is always used, when
C_DCACHE_USE_WRITEBACK is cleared to 0.
Read/Write
0/1
29
n-3
I Inhibit Caching
When bit is set to 1, accesses to the page are not cached (caching is
inhibited).
When cleared to 0, accesses to the page are cacheable.
Read/Write
0
30
n-2
M Memory Coherent
This bit is fixed to 0, because memory coherence is not implemented
on MicroBlaze.
Read Only
0
31
n-1
G Guarded
When bit is set to 1, speculative page accesses are not allowed
(memory is guarded).
When cleared to 0, speculative page accesses are allowed.
The G attribute can be used to protect memory-mapped I/O devices
from inappropriate instruction accesses.
Read/Write
0
1. The bit index n = C_ADDR_SIZE applies when PAE is enabled.
Table 2-20: Translation Look-Aside Buffer Low Register (TLBLO) (Cont’d)
Bits
1
Name Description Reset Value
