Yamaha Disklavier E3 - Page 182

MIDI Data Format
A-28
nn 42 1 00 - 7F SCALE TUNING C# -64 - +63 [cent] 40
nn 43 1 00 - 7F SCALE TUNING D -64 - +63 [cent] 40
nn 44 1 00 - 7F SCALE TUNING D# -64 - +63 [cent] 40
nn 45 1 00 - 7F SCALE TUNING E -64 - +63 [cent] 40
nn 46 1 00 - 7F SCALE TUNING F -64 - +63 [cent] 40
nn 47 1 00 - 7F SCALE TUNING F# -64 - +63 [cent] 40
nn 48 1 00 - 7F SCALE TUNING G -64 - +63 [cent] 40
nn 49 1 00 - 7F SCALE TUNING G# -64 - +63 [cent] 40
nn 4A 1 00 - 7F SCALE TUNING A -64 - +63 [cent] 40
nn 4B 1 00 - 7F SCALE TUNING A# -64 - +63 [cent] 40
nn 4C 1 00 - 7F SCALE TUNING B -64 - +63 [cent] 40
nn 4D 1 28 - 58 CAT PITCH CONTROL -24 - +24 [semitones] 40
nn 4E 1 00 - 7F CAT FILTER CONTROL -9600 - +9450 [cent] 40
nn 4F 1 00 - 7F CAT AMPLITUDE CONTROL -64 - +63 40
nn 50 1 00 - 7F CAT LFO PMOD DEPTH 0 - 127 00
nn 51 1 00 - 7F CAT LFO FMOD DEPTH 0 - 127 00
nn 52 1 00 - 7F CAT LFO AMOD DEPTH 0 - 127 00
nn 53 1 28 - 58 PAT PITCH CONTROL -24 - +24 [semitones] 40
nn 54 1 00 - 7F PAT FILTER CONTROL -9600 - +9450 [cent] 40
nn 55 1 00 - 7F PAT AMPLITUDE CONTROL -64 - +63 40
nn 56 1 00 - 7F PAT LFO PMOD DEPTH 0 - 127 00
nn 57 1 00 - 7F PAT LFO FMOD DEPTH 0 - 127 00
nn 58 1 00 - 7F PAT LFO AMOD DEPTH 0 - 127 00
nn 59 1 00 - 5F AC1 CONTROLLER NUMBER 0 - 95 10
nn 5A 1 28 - 58 AC1 PITCH CONTROL -24 - +24 [semitones] 40
nn 5B 1 00 - 7F AC1 FILTER CONTROL -9600 - +9450 [cent] 40
nn 5C 1 00 - 7F AC1 AMPLITUDE CONTROL -64 - +63 40
nn 5D 1 00 - 7F AC1 LFO PMOD DEPTH 0 - 127 00
nn 5E 1 00 - 7F AC1 LFO FMOD DEPTH 0 - 127 00
nn 5F 1 00 - 7F AC1 LFO AMOD DEPTH 0 - 127 00
nn 60 1 00 - 5F AC2 CONTROLLER NUMBER 0 - 95 11
nn 61 1 28 - 58 AC2 PITCH CONTROL -24 - +24 [semitones] 40
nn 62 1 00 - 7F AC2 FILTER CONTROL -9600 - +9450 [cent] 40
nn 63 1 00 - 7F AC2 AMPLITUDE CONTROL -64 - +63 40
nn 64 1 00 - 7F AC2 LFO PMOD DEPTH 0 - 127 00
nn 65 1 00 - 7F AC2 LFO FMOD DEPTH 0 - 127 00
nn 66 1 00 - 7F AC2 LFO AMOD DEPTH 0 - 127 00
nn 67 1 00 - 01 PORTAMENTO SWITCH 0/OFF, 1/ON 00
nn 68 1 00 - 7F PORTAMENTO TIME 0 - 127 00
nn 69 1 00 - 7F PITCH EG INITIAL LEVEL -64 -+63 40
nn 6A 1 00 - 7F PITCH EG ATTACK TIME -64 - +63 40
nn 6B 1 00 - 7F PITCH EG RELEASE LEVEL -64 - +63 40
nn 6C 1 00 - 7F PITCH EG RELEASE TIME -64 - +63 40
nn 6D 1 01 - 7F VELOCITY LIMIT LOW 1 - 127 01
nn 6E 1 01 - 7F VELOCITY LIMIT HIGH 1 - 127 7F
TOTAL SIZE 3F
nn = Part Number (0:1Part, 1:2Part, 2:3Part, ..., 15:16Part)
For the DRUM PART, the following parameters have no effect.
• SOFT PEDAL • PITCH EG INITIAL LEVEL
• BANK SELECT LSB • PITCH EG ATTACK TIME
• MONO/POLY • PITCH EG RELEASE LEVEL
• SCALE TUNING • PITCH EF RELEASE TIME
• PORTAMENTO • POLY AFTER TOUCH
<Table 1-5>
MIDI Parameter Change table (DRUM SETUP) [XG]
Address Size Data Parameter Description Default
(H) (H) (H) (H)
3n rr 00 1 00 - 7F PITCH COARSE -64 - +63 40
3n rr 01 1 00 - 7F PITCH FINE -64 - +63 [cent] 40
3n rr 02 1 00 - 7F LEVEL 0 - 127 Depends on the note
3n rr 03 1 00 - 7F ALTERNATE GROUP 0/OFF, 1 - 127 ”
3n rr 04 1 00 - 7F PAN 0/random, 1/L63 - 64/C - 127/R63 ”
3n rr 05 1 00 - 7F REVERB SEND 0 - 127 ”
3n rr 06 1 00 - 7F CHORUS SEND 0 - 127 ”
3n rr 07 1 00 - 7F VARIATION SEND 0 - 127 7F
