Yamaha F100A - Page 120

4-8
E
FUEL
CONTROL UNIT
EXPLODED DIAGRAM
6 × 25 mm
6 × 30 mm
5 × 25 mm
5 × 10 mm
1
2
3
5
4
6
7
8
9
10
11
12
13
6 × 12 mm
Step Procedure/Part name Q’ty Service points
8 Bolt 2
9 Spring pin 1
10 Spacer 1
11 Bolt 1
12 Throttle control lever 1
13 Bracket 1
Reverse the removal steps for installation.
