5-2
POWR
E
FLYWHEEL MAGNETO
SERVICE POINTS
CAUTION:
The major load should be applied in the
direction of the arrows. If the load is not
applied as shown, the flywheel holder may
easily slip off.
Flywheel magneto removal
1. Remove:
●
Flywheel magneto nut
Å
For USA and Canada
ı
For worldwide
Flywheel holder:
YB-06139/90890-06522
Å
ı
2. Remove:
●
Flywheel magneto
Å
For USA and CANADA
ı
For worldwide
CAUTION:
●
Keep the nut side flush with the crank-
shaft end until the flywheel magneto
comes off the tapered portion of the
crankshaft.
●
To prevent damage to the engine or
tools, screw in the universal-puller set-
bolts evenly and completely so that the
universal-puller plate is parallel to the fly-
wheel magneto.
Universal puller:
YB-06117/90890-06521
Å
ı
