Yamaha F100A - Forward Gear Bearing Installation; Forward Gear Bearing Removal

6-19
E
LOWR
LOWER CASE
3. Remove:
● Needle bearing
Driver rod:
YB-06071/90890-06652
Needle bearing attachment:
YB-06155/90890-06611
Forward gear bearing removal
1. Disassemble:
● Forward gear assy.
CAUTION:
Do not reuse the tapered roller bearing.
2. Remove:
● Tapered roller bearing outer race
● Forward gear shim(s)
Å For USA and CANADA
ı For worldwide
Bearing separator:
YB-06219/90890-06534
Slide hammer set:
YB-06096
Outer race puller claw:
90890-06532
Bearing outer race puller:
90890-06523
Å
ı
Forward gear bearing installation
1. Install:
● Tapered roller bearing
(onto the forward gear)
