Yamaha F100A - Starting System

8-16
–+
ELEC
E
STARTING SYSTEM
STARTING SYSTEM
B
B
R
R R RP
B
B
Br
Br
BB
B
R
RRR
R
R
B
R
Br
Br
Br
N
S
M
R
4
3
6
5
2
1
30 (A) 20 (A)
1 Fuse
2 10P coupler
3 Starter relay
4 Battery
5 Relay (magnetic switch)
6 Starter motor
B : Black
Br : Brown
R : Red
