Yamaha F100A - Drive Shaft Bearing Removal; Service Points

6-18
E
LOWR
LOWER CASE
SERVICE POINTS
Drive shaft removal
1. Remove:
● Pinion gear nut
2. Remove:
● Pinion gear
● Forward gear assy.
Drive shaft bearing removal
1. Remove:
● Drive shaft bearing
Å For USA and CANADA
ı For worldwide
Drive shaft holder:
YB-06151/90890-06519
Pinion nut holder:
90890-06505
Adapter:
90890-06507
Bearing separator:
YB-06219
Bearing inner race installer:
90890-06639
Å
ı
2. Remove:
● Drive shaft bearing outer race
● Pinion gear shim(s)
Å For USA and CANADA
ı For worldwide
Slide hammer set:
YB-06096
Stopper guide plate:
90890-06501
Bearing puller:
90890-06535
Stopper guide stand:
90890-06538
Bearing puller claw:
90890-06536
Å
ı
