Yamaha F100A - Propeller Shaft Housing Installation

6-13
E
LOWR
PROPELLER SHAFT HOUSING ASSY.
Propeller shaft housing installation
1. Install:
● Propeller shaft housing assy.
● Straight key
● Claw washer
● Ring nut
NOTE:
To secure the ring nut, bend one claw
washer tab into the slot in the ring nut and
the other tabs toward the propeller shaft
housing assy.
Ring nut wrench:
YB-34447/90890-06511
Extension:
90890-06513
T
R
.
.
Ring nut:
100 Nm (10.0 m • kg, 72 ft • lb)
