Yamaha F100A - Propeller Shaft Housing Assy. Disassembly; Propeller Shaft Housing Assy. Removal

6-10
E
LOWR
PROPELLER SHAFT HOUSING ASSY.
SERVICE POINTS
Propeller shaft housing assy. removal
1. Straighten:
● Claw washer tabs
2. Remove:
● Ring nut
● Claw washer
3. Remove:
● Propeller shaft housing assy.
● Straight key
Å For USA and CANADA
ı For worldwide
Ring nut wrench:
YB-34447/90890-06511
Extension:
90890-06513
Bearing housing puller:
YB-06207/90890-06502
Universal puller:
YB-06117
Stopper guide plate:
90890-06501
Center bolt:
90890-06504
Å
ı
Propeller shaft housing assy. disassembly
1. Remove:
● Reverse gear
Å For USA and CANADA
ı For worldwide
Slide hammer:
YB-06096
Bearing separator:
YB-06219/90890-06534
Stopper guide plate:
90890-06501
Stopper guide stand:
90890-06538
Bearing puller:
90890-06535
Claw:
90890-06536
Å
ı
